Chapter 18 Outbound Line Group
X6004 User’s Guide
299
DDI/DID
Mapping
Setting
Representative
Number
This field displays the representative number of the SIP trunk if you
have configured one in the SIP trunk setting (see
).
DDI/DID Mask
Enter a number (1~10) to decide the number of digits you want to
enter for the next DDI/DID number(s).
DDI/DID
Number
Enter a DDI/DID number which allows outsiders to call and reach an
extension directly. The number of digits you can enter in this field
depends on what you set in the Representative Number DDI/DID
Mask field.
This field can be 1-10 digits or 1-10 digits - 1-10 digits (two sets of up
to ten digits separated by a hyphen). For example, 5783900 or
5783900-5783999.
Extension
Number
Select the first radio box and enter the extension number to which the
DDI/DID number maps. Alternatively, select Auto-Attendant to
forward the matched DDI calls to auto-attendant.
This field can be 1-10 digits or 1-10 digits - 1-10 digits (two sets of up
to ten digits separated by a hyphen). For example, 5783900 or
5783900-5783999.
Add
Click this to add a new DDI/DID-to-extension mapping rule.
Apply
Click this to save your changes and to apply them to the X6004.
Cancel
Click this to go to the Outbound Group screen without saving your
changes.
Table 97 AA for SIP Trunks (continued)
LABEL
DESCRIPTION
