Chapter 5 Network Deployment
X6004 User’s Guide
136
5.6 The Static Route Screen
In a subnetted LAN environment the X6004 is typically connected to a router. The
router specifies the subnet to which the X6004 is directly connected and the
X6004 has no knowledge of the subnets beyond. For instance, the X6004 knows
about the IP phones in subnet N1 in the following figure. However, the X6004 is
unable to route a packet to phones in subnet N2 because it doesn't know that
there is a route through Router 1 (R). Static routes tell the X6004 about the
subnets beyond the router to which it is directly connected.
Figure 47 Example of Static Routing Topology
Time Zone
Setup
Time Zone
Select the time zone at your location.
Enable Daylight
saving Select this if your location uses daylight savings time. Daylight savings
is a period from late spring to early fall when many places set their
clocks ahead of normal local time by one hour to give more daytime
light in the evening.
Start Date Enter which hour on which day of which week of which month daylight-
savings time starts.
End Date Enter which hour on which day of which week of which month daylight-
savings time ends.
Offset Enter the amount of time (1,1.5, 2, 2.5,... or 5.5 in hours) by which to
adjust the time during daylight saving period.
Apply Click this to save your changes.
Reset Click this to set every field in this screen to its last-saved value.
Table 17 Network > NTP (continued)
LABEL DESCRIPTION
Internet
