Chapter 6 Server
X6004 User’s Guide
155
Figure 59 Settings for PRI Switch Types
Each field is described in the following table.
Table 26 Server > PRI Configuration
LABEL DESCRIPTION
PRI
Configuration Use these fields to specify the ISDN PRI interface which you want to
configure.
Machine ID Specify the X6004 for which you want to configure ISDN PRI settings.
This field is only configurable if you have more than one X6004 working
in a ZyStack.
Slot Specify which ISDN PRI interface card you want to configure. The cards
are identified by the extension card slot they are installed in. Select one
of the slots or select All to make the settings the same for all ISDN PRI
interface cards.
Port Specify the PRI port on the ISDN PRI interface card you want to
configure.
Switch Type Select a switch type depending on T1 or E1 mode and the technology
your telephone company uses. You can select 4ESS, 5ESS, DMS or
NI2 switch type if you connect the port to a T1 line while you can select
NET5, AUS or Q.SIG switch type if you connect the port to a E1 line.
4ESS
Q.SIG
DMS 5ESS
AUS
NI2 NET5
