Chapter 31 Diagnostics
X6004 User’s Guide
445
Stop capture
after.. Packets Specify how many packets you want to collect before ending the packet
capture. If you select to limit the capture by the number of packets and
by total time of the capture, then the capture session will end when the
time limit is reached.
Note: You must specify either a time limit or a total number of
packets limit for the data capture.
Stop capture
after.. Sec. Specify how long a packet capture session should last. If you select to
limit the capture by the number of packets and by total time of the
capture, then the capture session will end when the time limit is
reached.
If you do not specify any limits for the capture, then the capture will
last for the maximum time allowed (600 seconds).
Note: You must specify either a time limit or a total number of
packets limit for the data capture.
Capture Now /
Stop Capture Click Capture Now to start collecting network traffic information going
through the X6004. The Stop Capture button appears after you
successfully start a network traffic collection. You can click it to stop the
collection any time.
Note: It may take several minutes to perform the data collection. Do
not try to browse to other screens while the capture is in
progress.
Filename This field displays the name of the .cap file which holds the packet
capture data. The file naming convention is: X6004-YYYYMMDD.cap,
where YYYY is the year, MM is the month and DD is the day of the
month on which the capture took place.
Last Modified This field displays the date and time when the information was collected
from the X6004.
Size This field displays the size of the file.
Download Click Download to save the file to your computer.
Table 173 Diagnostics > Packet Capture (continued)
LABEL DESCRIPTION
