Chapter 21 Group Management
X6004 User’s Guide
337
Each field is described in the following table.
Table 111 PBX > Group Management
LABEL DESCRIPTION
Overview Click this to open the Overview screen.
Authority
Group,
FXO Trunk,
BRI Trunk,
PRI Trunk,
SIP Trunk,
Trusted Peer,
Click to Talk
These headings separate the group types you can manage on the
X6004:
• Authority Group - These are the authority groups containing
extensions on the X6004.
• FXO Trunk - These are outside lines via the FXO ports on the
X6004.
• PRI Trunk - This refers to a connection from the X6004 to the ISDN
T1 or E1 trunk line via the PRI port on the X6004.
• BRI Trunk - This refers to a connection from the X6004 to the basic
rate ISDN trunk line via the BRI port on the X6004.
• SIP Trunk - These are outside lines to a SIP server at your VoIP
service provider.
• Trusted Peer - These are outside lines to another SIP server (for
example another X6004) that has configured your X6004 as a
Trusted Peer.
• Click to Talk Group - These are Click To Talk groups on the X6004.
Machine ID This field displays the ID of the X6004 on which a group is configured.
Group Name This field displays the name of a group (authority group or an outbound
line group).
Description This field displays the description of this group.
Associations Click the Advanced icon to configure links for an authority or an
outbound line group.
