Components of Audio Processor

577

Hangs up the telephone.

Digit Keys:

16 Digit Keys at the left part of the control window on the panel includes numbers "0" to "9",
symbols "*" and "#", letters from "A" to "D". The numbers will be shown in the "Current Number"
field while dialing. Note: If pressing digit keys during a phone call, this component sends a
DTMF signal to the remote.

Current Number:

Records the number dialed or displays incoming calls.

Back:

Erases the last digit of the current Number.

Last Number:

The latest number dialed.

Redial:

Redials the Last Number.

Dialing:

Indicates the telephone card is dialing.

Ringing:

Indicates an incoming call needs to be accepted.

Set:

The LED lights up if the external telephone connected to the telephone card is off the hook.

Ready:

Indicates the status of the telephone card. This LED lights up if the telephone line is ready to
make a call.

Connect:

Indicates the telephone card is making a call.

Busy:

The LED shows the remote telephone is in the busy state and is not allowed to accept any
other calls.

MCU:

Reserved for displaying the engineering status.

Fault:

Determines if there is an error on the telephone line or not.

Mute:

Mutes the transmitting audio.
