Components of Audio Processor
553
© 2012 ATEÏS
Level:
The signal output level of the module.
Overload thd.:
Sets the threshold of the overload indicator.
6.19.5 Duplex Output
Component Template:
Component Appearance:
Description:
For AES/EBU output, the duplex output modules represent the physical outputs accessible on the
rear panel of the device. There are several separate modules for use with each of the audio boards.
Input and output modules are added automatically to the DSP window of the relevant processor by
defining their module configuration at the time you create them and should not be altered.
Control Window:
