Signal Path Lock
In this mode, by selecting a signal link, the signal link and the entire signal path linked will be
highlighted in red, then the mouse cursor will change into
, asking you to select the link
again, in order to lock it. The signal path is locked. To cancel it you have to select the mode
"Signal Path Disable
".
In this example, input C1 is routed in the matrix to outputs 1 and 2. If you place and select the
link of channel 1, then the signal path on outputs 1 and 2 will be displayed in red.
