ATEIS - IDA8

238

processor.

5. Fireman Microphone Connector

DIN Connector for fireman microphone connection.

6. Talk Indicator

This LED light up if PCP is allowed to paging, on the other word, the paging request has been
acknowledged.

Sometime after paging request is granted, zones under paging still can be occupied by other

sources. In such a case, the talk led still light up, but you can check busy LED to know the
situation.

7. LED Test Button

Test LED on control panel, after pressing this button all LEDs light up and then off.

8. Hold Indicator(1~8)

These LEDs Indicate which keys are selected.

9. All Call Release Button

This button is used to select or deselect all keys.

10.All Call Release Indicator

This indicator lights up if all keys are selected.

11.Event Select Key(1~8)

These buttons are used to select keys, each key may link to an event for triggering actions like
paging or adjust the value of parameters.

12.Busy Indicator(9~16)

Please refer to Busy Indicator(1~8).

13.Hold Indicator(9~16)

Please refer to Hold Indicator(1~8).

14.Event Select Key(9~16)

Please refer to Event Select Key(1~8).

15.Power Indicator

This LED light up when the CD8 is powered on.

16.EVAC Indicator

Light up when the system is under evacuation paging.

Status

Frequency

Activity

Permanent

System is under evacuation paging.

Blinking

CD-16 does not do a "Plug-in" in Ateis Studio before using.
