Name:
The object of the design window that corresponds to the device. After the relation of the object
and device is created, the configuration of the object will set to the device after executing the
"store" procedure.
Communication:
Shows the communication state of Ateis Studio and the device.
Device Function:
Lists all available functions of the device which will be told in each topic later.
Settings Tab:
Switches to a different tab for desired settings:
Device:
Searches and lists Ateis devices in the local area network.
Network:
Network interface card settings for communicating with Ateis devices.
RS232:
RS232 interface settings for communicating with Ateis devices.
Search Devices:
Search:
Attempts to discover the Ateis devices on the network.
Clear:
Clears the current search results and empties the grid.
Search Timeout Interval:
Determines the length of time the device will reply to the search command.
Search by IP:
If you already know the IP address of a device, you can search for it by that address.
5.4.1 Search and Settings
Search and connect to a device for further editing:
1. Before searching the Ateis devices in the LAN, the device information area is empty as shown in
the picture below.
2. Click the [Search] button under the Devices tab, the device list will appear after few seconds.
