Element Description:
Min Gain:
The minimum AGC level compensation.
Max Gain:
The maximum AGC level compensation.
Sampling Time:
Determines the period of time between two ambient noise measures. The less the value the
more sensitivity which means the compensation gain of paging input responds more quickly to
environment noise.
Target Level:
Determines which relative volume you want to target.
White Noise Level:
The white noise level which is automatically adjusted by the calibration.
Noise Threshold:
The level of background noise measured when the calibration button pressed.
AGC Level:
Displays the current compensation gain.
Calibration:
Click on to start the automatic calibration process.
Calibration Proceeding:
Lights up along the calibration process.
Calibration Finish:
Green LED, light up if the calibration process is success.
Over:
Indicates the calibration result. The white noise level needed is over the range. A pop-up window
will show you what to do.
Under:
Indicates the calibration result. The white noise level needed is under the range.A pop-up
window will show you what to do.
AR Time:
The attack and release time.
Paging Activity:
Lights up when the paging is active while the P.M. is above the mode threshold.
Decrease Zone:
