ATEIS - IDA8 42
© 2012 ATEÏS
Device Connection Max. Num Function
CD Touch PDC 1
Wall mounted cabinet remote paging console with touch screen
and Fireman Microphone.
PCP PDC 31
Wall mounted cabinet remote paging console with telephone
styled microphone.
CDPM PDC 31
Wall mounted cabinet remote paging console with 24 buttons/
zones and 2 extra selectable microphone sources.
PSC PDC 31
A grouped console is comprised of a pad with a monitoring
speaker, a pad with a gooseneck and 8 buttons/zones, and two
pads with 8 buttons/zones.
Deskpad PDC 1
A remote dialer for making telephone calls via IDA8's telephone
hardware.
Deskpad
Box
PDC 1
An RF transceiver to communication between Deskpad and
IDA8, use it, Deskpad can work without a physical connection.
Max. Num means you can connect one or more peripheral units through the connector by using a
Junction Box. For example: On the PDC, you can connect 32 PPM AS through junction boxes
and are able to assign IDs in sequence for each unit in Ateis Studio. Note: One IDA8C has 4 PDC
ports, and the sum of remote units is 32. Basically, fireman MIC already has one position
allocated, so this table only shows the maximum as 31.
If a large number of remote units is required , simply add more slave units for the master unit.
Eth. Limit: The maximum number of IP that can be assigned over the network.
4.1.1.6 3rd Party Control
The following table lists 3rd Party Control protocols which are IDA8C Supported.
Protocol
Interface
Function
Connection Settings
Ateis 3rd
Party
Protocol
Ethernet(UDP)
UDP Port =
19761
Read/Write value of parameters.
Stepped adjustment for parameters.
Modbus
Ethernet(TCP)
PDC(RS485)
TCP Port = 502
PDC Port 1~ 4
Level control
Paging
Read Monitoring Status
Read Evacuation Status
Play Message
Logic I/O Control
4.1.1.7 LCD Menu
The IDA8C has a 3.5" Color touch panel which offers a graphical interface for users to control or read the
status of system. There is a multi layered menu on it to get/set parameters or change settings of device.
Not only by the touch screen, you can also use the following buttons to get the access to some
functions.
ESC Button: To Navigate menu of touch screen.
OK Button: To Navigate menu of touch screen.
Up Button: To Navigate menu of touch screen.
