18-1
Z
ILOG
ISCC ™
C
ONTROLLER
Q UESTIONS AND A
NSWERS
ISCC QUESTIONS AND ANSWERS
Q. Is the interrupt vector present on both the lower
8 bits and the upper 8 bits in an interrupt cycle (See
Figure 40 of the Z16C35 CMOS ISCC Product
Spec)?
A. Both halves of the AD bus are driven during an inter-
rupt acknowledge cycle by the ISCC. In fact, both
halves of the data bus are never driven individually.
Q. In DMA mode, must the /WAIT//READY and
/BUSACK signals be externally synchronized to
PCLK (See Figure 46 of the Z16C35 CMOS ISCC
Product Spec)?
A. No, not exactly. The documented timing shows when
the ISCC samples these coming back from memory.
Q. Can the address and data bus be outputted before
/BUSACK is received (See Figure 46 of Z16C35
CMOS ISCC Product Spec)?
A. No.
Q. What causes the Terminal Count to be Reset?
A. Refer to P.5-26 TM, Sec. 5.6.2, “the status in this reg-
ister is automatically cleared after a Read.” In other
words the bits are Reset when you Read the contents
of the register.
Q. Which Rev of the SCC is in the ISCC?
A. It is the D Rev (but without the oscillator fix).
Q. Does the ISCC allow software interrupt acknowl-
edge (WR9 bit D5)?
A. Yes, it does. It is not required to use the /INTACK sig-
nal of the ISCC to process interrupts. The source of the
interrupt can be determined by reading the interrupt
vector just like a normal interrupt is determined by
reading the interrupt vector (like a normal register
Read). The SCC RR2B is modified to reflect the
source. RR2A is not modified. Also, the other status
registers could be used to figure out who interrupted.
SCC interrupts can be Reset by reading RR2B if soft-
ware interrupt acknowledge is enabled (WR9 D5=1).
Q. Does the software interrupt acknowledge support
DMA operation?
A. No. Unlike the SCC core, the DMA core does not sup-
port this feature. The DMA has two sources of the in-
terrupt, i.e., IP and IUS bits.
Q. When the ISCC is used on a multiplexed bus, the
ISCC does not interrupt when the SCC source in-
terrupts occur until after another Write to the ISCC.
Why?
A. When programmed for multiplexed bus operation, sim-
ilar to the Z8030/Z80C30, the /AS signal is used to up-
date the interrupt status of the SCC. Consequently, if
no /AS is present, the interrupt status is not updated
until an /AS occurs. If /AS of the ISCC is tied to the /AS
of the processor, sufficient /AS signals will occur to
keep the ISCC interrupts up to date. However, if /AS is
only generated to the ISCC when it is being accessed,
any pending SCC interrupts will not assert the /INT pin
until after the /AS of an access to the part. This typical-
ly occurs when a PAL is used to generate the access
signals to the ISCC and /AS is only generated to the
ISCC when it is being accessed.
Q. Can the Upper Address Strobe be defeated (to
shorten the transfer cycle time)?
A. No. But this is possible in the IUSC!
Q. How many clock cycles does it take to do a DMA
transfer, after BUSACK is granted?
A. By looking at Figure 45 of Z16C35 CMOS ISCC Prod-
uct Spec, it takes TS0, TS1, T0, T1, T2, T3, T4, T5,
about 8 cycles total.
Q. Is there any reason why the ISCC couldn’t use pclk
twice as fast as the processor, in order to cut ac-
cess recovery times?
A. No, as long as the required timings are met!
