96
TPS1100 - Appl. Prog. Ref. Manual 2.2.0en Area
Record
For each section of the area, start
point and end point, horizontal
distance and azimuth are stored.
For arcs with 2 points and radius the
azimuth of arc, radius and length of
arc are also stored.
For 3 point arcs the direction of arc,
radius and length of arc are also
stored.
Leica Geosystems Program Area V 1.00
Instrument
: TCM1103, Serial 102999
Meas. file : MYFILE.GSI
Program Start : 20/04/1998 at 09:42
Segment Number : 1
Start Point : 1
End Point : 2
H Distance : 5.5555m
Azimuth : 140°11'17"
Segment Number : 2
Start Point : 2
End Point : 4
Curve Right/Radius : 4.9089m
ARC Length : 2.326m
Segment Number : 3
Start Point : 4
Second Point : 5
End Point : 6
Curve Right/Radius : 5.362m
ARC Length : 2.254m
Number of Segments : 3
Area : 9.8496m2
Hectares : 0.0010
Perimeter : 13.8396m
Typical log file entry in the "AREA" program
Log File, continued
