166
TPS1100 - Appl. Prog. Ref. Manual 2.2.0en COGO
Enter lateral deviation/distance
(Offset): INPUT Entering lateral
deviation/distance
RCALL Call up of a lateral
deviation/distance which has been
previously stored using the function
"Polar calculation".
Changing the direction
(as dialog box "Modify
Distance").
Exit the program.
Horz.Dist.
Enter lateral deviation/distance
(Offset)
Accept displayed values.
Determining the lateral
deviation/distance (Offset) by
means of the function "Polar
calculation"
(refer to chapter
"Inverse").
The following dialog box shows the
results of the orthogonal point
calculation:
Point Id
Entering point number of the lateral
point
East
Display of east coordinate
North
Display of north coordinate
Elevation
Entering height (optional)
Orthogonal point calculation, continued
COGO\ Offset Results
Point Id : -----
East : 0.000 m
North : 0.000 m
Elevation : -----
CONT NEW STORE STAKE
MC
QUIT
COGO\ Offset
Perpendicular offset from BL
Offset : 0.000 m
CONT INV RCALL
MC
QUIT
