238
TPS1100 - Appl. Prog. Ref. Manual 2.2.0en Road+
Cross Sections Assignments
Elements supported:
Element Definition
Cross Section
number The number or identifier of the cross section
Chainage The chainage from which the cross section is applied
Header of the Cross Section Assignment File:
410001+000ASKER 42..10+ASSIGNMT 43....+CRSASKER
WI41 Job identification. Max. 8 ASCII characters, user definable.
WI42 Cross section assignment file identification. May not be changed
by user. Data units are defined by characters 6+7 of WI42.
WI43 Name of the corresponding cross section file.
A data block for a cross section assignment is structured as follows:
110002+0000NORM 71....+00382000
WI 11 The cross section number or identifier
WI 71 Beginning chainage for that cross section
Comments:
• A cross section assignment file
must have a corresponding cross
section file.
• A cross section remains valid until
a new cross section is assigned.
• A given cross section may be
assigned more than once.
• The units for station (chainage) are
defined in WI 42 in the file header.
