Traverse
Records manually entered
station data on the active
recording device. The program
proceeds to the "Measure Mode"
dialog.
Set horizontal-circle direction.
For further information,
please refer to chapter "Measure &
Record" of "System" - user manual.
Import station coordinates.
For further information,
please refer to chapter "Setup" of
"System" - user manual.
Press this key
combination to import
and view the stored coordinates of a
point.
Inst. Ht.
(Optional, but necessary to correctly
compute elevations.) Input the height
of the instrument tilting axis above
the occupied station.
Stn.East
Input the Easting, or X ordinate, of
the occupied station. The station
coordinates may be imported using
the IMPOR hotkey.
Stn.North
Input the Northing, or Y ordinate, of
the occupied station.
Stn.Elev
(Optional, but necessary to compute
elevations.) Input the Elevation, or Z
ordinate, of the occupied station.
Hz
The current horizontal circle value.
• Select method of orientation
Three different methods orientation
are available
1. Confirm the orientation already set
in the system.
1
No measurements
are performed (SYS).
2. Calculation of an azimuth from
coordinates to one tie point. A
following measurement to the tie
point orients the Hz-circle (INPUT).
(See "Calculation Azimuth".
3. Manual input of the azimuth to one
tie point. A measurement to the tie
point is required (AZI).
(See "Enter Backsight Azimuth")
1
If the orientation was previously
determined with the
"ORIENTATION" program, for
example.
New traverse, continued
