82
TPS1100 - Appl. Prog. Ref. Manual 2.2.0en Remote Height
Configuration
Depending on the
configuration that is loaded
onto your TPS1100 instrument, you
may not see some or all of the
options referred to below. See your
Leica Geosystems dealer for more
information about the configuration of
your instrument.
Start the
"Configuration Editor"
from the "Measure Remote point"
dialog.
The "Configuration Editor" sets
parameters for further program
operations:
User Disp
Set to YES, the display defined in the
"MEAS" application will be used.
If set to NO, the "REMOTE HEIGHT"
default display applies.
Hz.Pos.Tol
Horizontal distance tolerance that
valid point measurements cannot
exceed.
Rec
∆∆∆∆∆
Ht
NO The Height difference
∆∆∆∆∆
Ht.diff
between remote and base
point is not recorded.
Rec in WI37
∆∆∆∆∆
Ht.diff is stored as record
WI37 in the measurement job.
Meas Job
Selection of the measurement job for
recording measurements.
Data Job
Selection of the data job containing
the fix point coordinates (control
data).
Accept the current
configuration and proceed to
the dialog "MEASURE BASE PT".
Reset configuration
parameters to their default
values.
Displays date and version of
the running application.
REMHT\ Configuration
User Disp.: NO
Hz.Pos.Tol: 0.200 m
Rec ∆∆∆∆∆ Ht : NO
Meas Job : FILE01.GSI
Data Job : DEFAULT.GSI
CONT DEFLT INFO
MC
QUIT
