243
TPS1100 - Appl. Prog. Ref. Manual 2.2.0en Road+
Log File, continued
Example of a log file for the
program "Road+":
Leica Geosystems VIP RoadPlus V 0.90
Instrument
: TPS1100, Serial 400001,
Meas. File : FILE01.GSI
Program Start : 02/07/1998 at 10:37
Horizontal Aln : ALNSPORT.GSI
Vertical Aln : PRFSPORT.GSI
Cross Sections : CRSSPORT.GSI
Station no. : 1
E= 0.000m N= 0.000m ELV= 0.000m
hi= 1.6000m
Point No. : 55
Chainage : 150.000, Offset= 0.000m, Hght Offset= 0.000m
Design : E= -79.269m, N= 19.917m, ELV= 400.501m
Staked : E= -1.057m, N= 2.578m, ELV= 0.107m
Deltas : dE= -78.211m, dN= 17.339m, dELV= 400.394m
Point No. : 5
Chainage : 100.000, Offset= 0.000m, Hght Offset= 0.000m
Design : E= -46.305m, N= 26.708m, ELV= 400.409m
Staked : E= -0.000m, N= 2.774m, ELV= 0.051m
Deltas : dE= -46.305m, dN= 23.934m, dELV= 400.358m
Point No. : 5
Chainage : 100.785, Offset= 0.000m, Hght Offset= 0.000m
Design : E= -46.688m, N= 27.392m, ELV= 400.365m
Staked : E= -0.000m, N= 2.774m, ELV= 0.051m
Deltas : dE= -46.688m, dN= 24.619m, dELV= 400.314m
