TPS1100 - Appl. Prog. Ref. Manual 2.2.0en Stakeout
Hz Angle 2
Angle from the second auxiliary point
to the stakeout point.
Dist 2
Distance from the second auxiliary
point to the stakeout point.
∆∆∆∆∆
Height
Difference in height between the last
measured reflector point and the
stakeout point. Positive in sign if
stakeout point is higher than the
reflector position.
Simultaneously measure and
record data in the
measurement job
Measure a distance.
Record the measurement in
the measurement job.
Acquire the next point to
stake.
Enter target data.
Re-position the telescope on
the target. Note, this function
is only available for motorized
theodolites.
Change stakeout
method.
For more information refer to chapter
"Select Stakeout Method".
Generate a plot of the
stakeout data. For
more information refer to chapter
"Plot".
Exit the program.
Stakeout with auxiliary points, continued
Point Id
Point Id of the point to be staked.
Refl. Ht
Reflector height used at target point
Hz Angle 1
Angle from the first auxiliary point to
the stakeout point.
Dist 1
Distance from the first auxiliary point
to the stakeout point.
STAKE\ Auxiliary points
Point Id : 12
Refl. Ht. : 1.65 m
Hz angle 1 :* ----- m
Dist 1 : ----- m
Hz angle 2 :* ----- m
Dist 2 : ----- m
ALL DIST REC CONT POSIT
MC
METHD I<>II QUIT
∆∆∆∆∆ Height : ----- m
