33
TPS1100 - Appl. Prog. Ref. Manual 2.2.0en Tie Distance
WI 37 Height difference between
point 1 and point 2
WI 39 Slope distance
WI 79 Point number of point 1 or
center point number
Toggle between Radial/
Polygon Mode.
Depending on the
configuration that is loaded
onto your TPS1100 instrument, you
may not see some or all of the
options referred to below. See your
Leica Geosystems dealer for more
information about the configuration of
your instrument.
Configuration
Configuration Editor
Start the
"Configuration Editor"
from the "First Point" dialog.
The "Configuration Editor" sets
parameters for further program
operations:
Two Faces
YES for dual-face measurement,
NO
for single-face.
Results, continued
TieD\ Configuration
Two Faces : NO
User Disp.: NO
Log File : Off
Log FlName: TIEDIST.LOG
Meas Job : FILE01.GSI
Data Job : FILE02.GSI
CONT DEFLT INFO
MC
QUIT
