56
TPS1100 - Appl. Prog. Ref. Manual 2.2.0en Free Station
Measure Mode
This dialog is similar to the
TPS1100's basic "MEASURE MODE"
dialog. Once a measurement is
taken, the program will return to the
dialog "Target Point" to acquire the
next point for measuring.
If the station coordinates can be
calculated successfully from the first
few measurements, the
∆
Hz and
∆
V
values are displayed for further
entered target points. Motorized
theodolites will automatically drive the
telescope to the target point.
Simultaneously measure and
record data in the active
measurement job. Return to the
dialog "TARGET POINT".
Measure a distance.
Record the measurement in
the active measurement job.
Return to the dialog "Target Point".
Accept the measurement and
return to the dialog "TARGET
POINT".
Enter target data.
(see User Manual)
Change the theodolite
face.
Exit the program.
Calculation
Calculates the 3D station coordinates
and orientation as well as the
standard deviation of the results.
Station Id
Point number assigned to the station
No. of Pts
Number of points measured
FreSt\ Measure
Point Id : 12
Hz : 286°55'50''
V : 91°16'20''
Refl. Ht. : 1.500 m
Slope Dist: 22.039 m
∆∆∆∆∆ Hz : ----- m
MC
I<>II QUIT
ALL DIST REC CONT TARGT
PLOT QUIT
Hz Ori. : 2°12'34''
σσσσσ East : 0.003 m
σσσσσ North : 0.005 m
σσσσσ Elev. : 0.005 m
σσσσσ Hz Ori. : 0°00'03''
Calc Scale: YES
Scale : 0.999956
FreSt\ Results (L.Sqrs)
Station Id: 1
No. of Pts: 6
Inst. Ht. : 1.635
East : 2134.234
North : 4231.365
Elevation : 580.643
MC
SET STORE MEAS MORE COMP
