148
TPS1100 - Appl. Prog. Ref. Manual 2.2.0en COGO
Add
Entering angle for a correction to the
right
Subtract
Entering angle for a correction to the
left
NorthEast
Display of corrected magnetic
bearings
Accept displayed values and
proceed with
dialog "Distance
to Traverse".
Defining direction by Azimuth
If "Azimuth" is selected in the
configuration for "Direc. Type:", then
the following dialog box appears:
COGO\ Traverse
Direction to Traverse
Azimuth : 0°00’00’’
Offset : 0.000 m
CONT INV RCALL
MC
MODIF QUIT
Azimuth
Entering Azimuth
Offset
Entering parallel displacement.
Only active if "YES" is entered in the
configuration during "Offset:"
Left = negative parallel offset
Right = positive parallel offset
Accept displayed values and
proceed with
dialog "Distance
to Traverse".
Determining the direction by
means of the function "Polar
calculation" (refer to chapter
"INVERSE").
INPUT Entering Azimuth
RCALL Call up of a
direction which has been previously
stored using the function "Polar
calculation".
Changing the direction
(refer to dialog "Modify
Azimuth ")
Exit the program.
Defining direction by magnetic bearing, cont.
