TPS1100 - Appl. Prog. Ref. Manual 2.2.0en

Free Station

Inst.Height
Instrument Height

East
Calculated Easting for the station

North
Calculated Northing for the station

Elevation
Calculated Elevation for the station

Hz. Ori
Oriented direction

East

Standard deviation of Easting

North

Standard deviation of Northing

Elev

Standard deviation of the Elevation

Hz. Ori

Standard deviation of the Orientation

Calc Scale
YES scale factor is calculated,
NO scale factor is not calculated
Note that this parameter is
displayed only if sufficient
measurement were taken.

Scale
The scale factor of the free station
calculation.
Note that the scale is not shown if
set to NO.

Set orientation and station
coordinates on the

instrument.

Record the following results
in the active measurement

job:
WI 11

Station Point Number

WI 25

Orientation correction

WI 84

Station Easting

WI 85

Station Northing

WI 86

Station Elevation

WI 87

Last reflector height used

WI 88

Instrument Height

Measure more points. The
program will recall the

"TARGET POINT" dialog.

Show the results of individual
measurements on the screen

(see dialog "More Information").

Compare the Free Station
results to the station

coordinates and orientation currently
set in the instrument.

Select between the
"Robust" method and

the Least Squares method.

Sketch of the station
and the reference

points used.

Exit the program.

Calculation, continued
