STC-2000A DEPOSITION CONTROLLER
y
When the STC-2000A sensor card control voltage output is connected to the evaporant power supply,
Review Source Sensor Map parameters need to be selected for a proper interface (
SOURCE OUT CHaNneL,
SOURCE FULL PoWeR, SOURCE MAX PoWeR
) and the Map itself needs to be selected by a Film parameter
(SS MAP SELECT). Following this, other power supply related parameters must also be contemplated.
Some thermal excitation alternatives include: electron beam: wire fed electron beam source, high vacuum
e-beam w/ small (~2cc) crucible, fixed pocket (large and small), rotary pocket indexers; resistive heater
sources: metal filament boats, coils, oxide crucibles (all for organic material deposition). Crucible
capacities can range from a fraction of a cc to over 500cc. The input control requirements of the high
current (or voltage) power supply should be found in the power supply documentation. Don't assume there
is a standard. With the STC-2000A control voltage output controlling the power supply for the thermal
sources described above (the 2
nd
control output voltage used for power supply control is typically employed
for the recorder function), the film parameters effecting power (processes depend upon films) are:
Soak 1 Power level Value
0.0 to 100.0%
Power Ramp 1 Time (to pwr level) 0 to 99:59 MM:SS
Power Soak 1 Time (@ pwr level) 0 to 99:59 MM:SS
Soak 2 Power level Value
0.0 to 100.0%
Power Ramp 2 Time (to pwr level) 0 to 99:59 MM:SS
Power Soak 2 Time (@ pwr level) 0 to 99:59 MM:SS
Soak 3 Power level Value
0.0 to 100.0%
Power Ramp 3 Time (to pwr level) 0 to 99:59 MM:SS
Control Loop –P-roportional term 1 to 9999
Control Loop –I-ntegral term
0.0 to 99.9 sec
Control Loop –D-erivative term
0.0 to 99.9 sec
Max Power Limit
0.0 to 100.0%
These parameters are presented
here for the purpose of name
familiarization and categorization
of power related parameters
across menu and screen
boundaries.
Abort Max Power SW
OFF/ON
Max Power Dwell
0:01-99:59 MM:SS
Control Loop Qual Limits
0 to 9
Plot Vert Scale Volts
1, 5, 10, 50, 100
⇐ Graphical display function
Plot Horiz Scale H
1 to 600 samples
⇐ Graphical display function
Data Plot Type
Rate /Power /Rate Deviation
⇐ Graphical display function
Source Sensor Map Select
1 to 10
(Selects the Map that contains Source Sensor analog output parameters)
Etching Mode
Off / On (
Rate Direction can be Positive or Negative)
The Power Related RunTime Screen parameters are:
(Crystal Quality Indicator Select) L/Q, Loop x, Qual xx
(Manual mode)
(fixed front panel key)
(Manual mode)
(pendant arrow keys [increase / decrease power manually])
(Manual
mode)
(2
nd
STATUS screen arrows:
[increase/decrease power manually])
(Manual
mode)
(2
nd
STATUS screen: zero power key [LCD] on non-active channels)
(Manual mode)
(3
rd
STATUS screen: zero thick key [LCD] no effect on material thickness)
(Manual
mode)
(3
rd
STATUS screen: force fail key [LCD] fail/verify crystal channels)
The Power Related System Configuration values are:
Menu path: Main/Executive menu/System Configuration]
Recorder Functions
Rate, Rate Deviation, Power, Thickness, Computer Remote, I/O, Off
Recorder Analog Output ChaNneL
2 Channels (select 1 only)
[note possible conflict w/ Source Analog Output]
The Power Related Review Source Sensor Map values are:
Menu path: Main/Review SS Map]
Source FS Voltage Scaling PoWeR*
2.5/5/10 Full Scale VOLTS
⇐
see Power Supply input requirement
Source Max PoWeR
0.0 – 100.0%
Source Analog Output CHaNneL
2 Channels (select 1 only)
The Power Related Service Menu values are:
Menu path: Main/Service]
(Memory Contents)
as is (no modification), purged, factory (defaults) [see section 3.21 ]
note
film
parameter
changes
(Reset)
Arm reset, reset armed [Provide a product reset when back panel power
