STC-2000A DEPOSITION CONTROLLER
y
Source Sensor Max Power Value 0.0% - 100.0%
Source Sensor Analog Output Chnl 1 – 2 Channel Selection
Master Tooling Value
10.0% - 400.0%
Minimum Start Xtal Channels
1 – 2 minimum channels
Minimum Backup Xtal Channels 0 – 1 minimum channels
Minumum Active Xtal Channels
1 – 2 minimum channels
(Xtal) Channel Drop Filter
NONE, BALANCE
[Mask dropped Xtal channel Failure]
averaging mode only
Indexer Synchronization Mode
NONE, DELAY, FEEDBACK
Indexer Synchronization Time
2 – 999 seconds
Channel 1 Start Mode
OFF, ACTIVE, STANDBY
Channel 1 Fail Action (Mode)
NONE, ABORT FILM
Channel 1 Backup List
X – XX (1 item list to 2 item list), [where X = 1 to 2 (in each position
w/o redundancies, list extends to 0-2 for a 1 item list)]
Channel 1 Tooling Value
10.0% - 400.0%
Channel 1 Weight
10.0% - 400.0%
Channel 2 Start Mode
OFF, ACTIVE, STANDBY
Channel 2 Fail Action (Mode)
NONE, ABORT FILM
Channel 2 Backup List
X – XX,
[X = 1 to 2 (in each position w/o redundancies)] see CH1
Channel 2 Tooling Value
10.0% - 400.0%
Channel 2 Weight
10.0% - 400.0%
I/O Function elements:
[Menu end point: I/O Setup
Menu path: Main/Executive menu/ I/O Setup]
I/O Relay Functions
user I/O program
(8 Form C Relays per card [4 slots available for I or O cards])
I/O Input Functions
user I/O program + PCB jumpers
(8 Inputs per card [4 slots for I or O cards])
I/O Setup
Memory: save/swap, Operate: run/stop
I/O Programming
Edit (Program): IN, NOT, AND, OR, XOR, POSitive, NEGative,
OUT, TRiP, SET, CLeaR, ARM, DRoP, (events/states/logical
operators), (softnodes) and (numeric elements).
Arithmetic operators/elements: KON# (to input constants), ADD,
SUBtract, MULtiply, DIVide, MODulus, EQUals, GReaTer than,
LESs than, and SELect. Editing: backspace, left/right arrows (to move
cursor), delete, undo, insert/delete line.
(Front Panel LEDs [4 discrete])
I/O programming elements (see table x in section 5xx and Section 2.2)
(User Front Panel Keys [4])
I/O programming elements (see table x in section 5xx and Section 2.2)
Pendent Keys
(beyond specified Manual Mode use: I/O programming elements
[see table xxx in section 5xx ])
Service Menu values:
[Menu end point: Service
Menu path: Main/Service]
(Test Mode Select)
Test Off, Test On [Test Mode won't remain in effect if power is cycled)
(Seq/Non-seq Mode Select)
Seq(uencing Mode Select en)able, Non-seq(uencing Select enabled)
(Memory Contents)
as is (no modification), purged, factory (defaults) [see section x.2.2xx ],
Memory Module to Unit or Unit to Memory Module [see section 3.20]
(Reset)
Arm reset, reset armed [Provide a product reset when back panel power
switch is not accessible. Also, use to generate ACCEPT key if not
present (e.g. to end the Test mode when in the Test mode).]
[Prerequisite states that must be in effect for the following parameters to be fully functional]
