STC-2000A DEPOSITION CONTROLLER
y
Description Request rung # 999 data (rungs will not go that high since data storage allows for a
maximum of 400 rungs). The end information indicates that the rung requested is beyond the last rung
which has program information in it. The number 12 after the end word indicates that rung # 12 is the end
rung, and rung # 11 is the last rung of the program containing boolean expressions.
Command N23
Response A
Description
Signal the desire to change or alter rung # 23. If no rung #23 exists (as is the case with
the program shipped with the unit, which stops at rung 11), then the end rung (#12 in this case) will be
changed, extending the program. Command understood and performed, future 'O' commands will reference
rung 23.
Command O.IO
0141
Response A
Description
Send a terminal packet (because of the '.') defining the selected rung as "I0 O141". This
sets the rung to input-from-0 output-to-softnode-141. Command understood and performed, rung modified.
New 'O' commands will require a new 'N' command prefix in order to specify which rung to modify or
change next.
Command N9
Response A
Description
Request Change To Rung 9. Command Understood And Performed.
Command
O0I45 I46 I47
Response A
Description
Enter 0th packet of rung symbolic. Command understood and performed.
Command O1I48+++
Response A
Description
Enter 1st packet of rung symbolic. Command understood and performed.
Command O.O141
Response A
Description
Enter final packet of rung symbolic. Command understood and performed, rung in place
as "I45 I46 I47 I48 + + + O141" .
Table 26.8: Group 9 Examples.
______________________________________________________________________
I/O Program Editing
I/O Program Editing Group 10 --
Commands P,Q,R,S
(P) (Q) (R) (S) I/O Editing Commands. This set of commands will do the following editing functions in
the I/O program:
P - Delete A Rung
Q - Select The I/O Program (Primary Or Alternate)
