4.8 Milling Cy
cles
Face milling
Call the milling menu.
Select the "Face milling" cycle.
Depending on the parameters, the cycle mills the following contours
on the face.
„ One or two surfaces (Q=1 or Q=2, B>0)
„ Rectangle (Q=4, L<>B)
„ Square (Q=4, L=B)
„ Triangle or polygon (Q=3 or Q>4, L>0)
„ Circle (Q=0, RE>0, L and B: No input)
