4 roughing cy cles – HEIDENHAIN MANUALplus 4110 User Manual
Page 100
100
4 Cycle Programming
4.4 Roughing Cy
cles
Expanded mode
Rounding
Expanded mode
Chamfer (or rounding) at contour end
Basic mode
Machining with descending contour
Basic mode
Oblique cut at contour end
Expanded mode
Rounding in contour valley (in both corners)
Expanded mode
Chamfer (or rounding) at contour start
Expanded mode
Chamfer (or rounding) at contour end
Contour elements in roughing cycles
