Page 136
Section 3: Screen Descriptions
WCC II Operator’s Guide
Operator Interfaces
3-104
Point Description Search
This feature allows you to fi nd and access a “point” within the ECC/
WCC II system by entering the words that have previously been
input in the “Description” fi eld on one or more of the following
screens:
Analog Input
Control Output
Time Clock Mode
Dual Limit Mode
EA Driver Mode
Analog Output
Logic Switch
TUC
In other words, if you want to fi nd the Analog Input Screen for the
outdoor air temperature sensor, and you know the description has
been entered as “OA Temp,” you can fi nd the screen by simply
entering “OA Temp.”
When you access this screen for the fi rst time, it will automatically
go through a process of searching for each satellite controller and
storing the data from the “Description” input on the screens listed
above. If you make any changes to the “Descriptions” after the
list has been generated, you need to manually force the system to
search the satellites again by moving the cursor to the “Home”
position on the Point Description Search Screen and pressing the
and then
, holding both keys down for an instant and
then releasing both keys at the same time.
A message will appear at the bottom of the screen asking which
satellite is to be rebuilt. Input the number of the satellite and press
.
Note:
Rebuilding tables for Search Screens is an entirely
different function than rebuilding data tables from the Utility
Screen.
String to Match: Rm 101
The “String to match” is the “Description” that has previously
been entered on one or more of the satellite screens. The system
will distinguish between small and capital letters, so you need to
remember exactly how the “Description” was entered.
If you do not remember the exact “Descriptions,” you can enter an
asterisk (*) as a wild card, and all of the descriptions will appear.
POINT DESCRIPTION SEARCH SCREEN
-----------------------------------------------------------------------------------------
-
Point Description Search
String to Match: Rm
Continue Present Search: No
Logical
Address
Description
Current
Status
1:
1A1
Rm101 Temp
76.2
2:
1A2
Rm102 Temp
73.2
3:
1A3
Rm103 Temp
75.2
4:
1k1h
Rm101 VAV
-->Cool
5:
1k2h
Rm101 Heat
Ht Off
6:
1k2c
Rm101 Fan
Fan Off
7:
1k3h
Rm102 VAV
-->Warm
8:
1k4h
Rm102 Heat
Ht On
9:
1k4c
Rm102 Fan
Fan On
10:
1k5h
Rm103
VAV
-->Cool
11:
1k6h
Rm103 Heat
Ht Off
12:
1k6c
Rm103 Fan
Fan Off
-----------------------------------------------------------------------------------------
