Configuring the switch 112
11. Use the scroll bar on the right side of the Configure Ports dialog box table to display additional
ports that you want to configure.
12. Activate changes and close the dialog box by clicking Activate.
13. If you have finished configuring the switch, back up the configuration data. For more
information, see ” Backing up and restoring configuration ” on page 158.
NOTE: If you have configured Port Binding and click Activate, an error message may
display if the format for the WWN entered in the Bound WWN column is not valid (not in
xx:xx:xx:xx:xx:xx:xx:xx format) or if you enter a nickname that has not been configured
through the Element Manager.
Configure Ports (FICON management style)
NOTE: This procedure applies only to the Edge Switch 2/32. FICON Management Style is not
available on the Edge Switch 2/24.
To configure Edge Switch 2/32 ports in FICON management style:
1. Select Configure > Ports.
The Configure Ports dialog box is displayed.
Figure 37 Configure Ports dialog box (FICON Management Style)
Ports are numbered from 0 through 31.
2. Use one of the following options:
