Element Manager overview

40

CAUTION:

Clearing the counters clears the statistics for all users.

For more information about the Performance view, including statistics descriptions, see

Performance

view

” on page 65.

FRU List view

To display the FRU List view, click the FRU List tab. A table, as shown in

Figure 8

, is displayed in the

View panel. This table included information about each FRU installed in the switch. All data is

dynamic and updates automatically.

Figure 8

FRU List view

Double-click a row to display the FRU Properties for the selected FRU.
For details on navigating and monitoring via the FRU List view, see ”

FRU List view

” on page 70.
