Edge Switch Element Manager user guide

79

Configuring management style

To configure management style for the Edge Switch 2/32 only:

1.

Set the director off line.

2.

Click Product > Management Style.

NOTE:

If you change the management style to FICON, all ISL/E-Ports are disabled.

3.

Click either the Open Systems or FICON option buttons:
• Use Open Systems management style for all (non-FICON) Fibre Channel environments.
FICON is the default management style if the FICON Management Server feature is

enabled. In addition, you cannot change the management style to Open Systems with the

FICON Management Server feature enabled. Typically, FICON Management Style is used

when attaching an IBM FICON Parallel Enterprise or IBM zSeries server to the director and

implementing in-band director management through a Fibre Connection (FICON) channel.

Configuring operating parameters

Use the procedures in this section to set parameters on the switch for switch and fabric operation.

These operating parameters are stored in NV-RAM on the switch.

Configuring switch parameters

Use procedures in this section to set parameters on the switch for switch operation through the

Configure Switch Parameters dialog box.
To set switch parameters:

NOTE:

The switch must be off line to change Preferred Domain ID. If it is not and you activate

values in this dialog box, a dialog box is displayed, prompting you to set the unit off line.

CAUTION:

Setting the switch off line terminates all Fibre Channel connections.

1.

Set the unit off line:
a. Select Maintenance > Set Online State.
b. When the Set Online State dialog box is displayed, click Set Offline.
c. When the warning box is displayed asking you to confirm the off line state, click OK.
