Edge Switch Element Manager user guide
31
NOTE:
The ACP Prohibited check box is only visible for switches that support ACP.
Logs menu
The Element Manager provides logs that show a record of various events that have occurred on the
switch. Select the Logs menu to display the following logs.
For detailed information on using the log dialog boxes, see ”
•
Audit Log—Provides a record of all configuration changes made on the switch. Each entry
displays the date and time of the change, a description of the change, the source of the change
(such as the HAFM appliance or SNMP management station), and an identifier for the source,
such as the IP address of the HAFM appliance or SNMP management station. See ”
•
Event Log—Provides a record of significant events that have occurred on the switch, such as
hardware failures, degraded operation, and port problems. Each entry includes the date and
time of the event, a reason code for the event, a brief description, the severity level, and up to 32
bytes of supplementary event data. Refer to the appropriate service manual for your Edge Switch
for more information. See ”
•
Hardware Log—Provides information on FRUs inserted and removed from the switch. Each log
entry includes the date and time the FRU was inserted or removed, the name of the FRU inserted
or removed, the slot position relative to identical FRUs installed, whether the FRU was inserted or
removed, the FRU part number and serial number. See ”
•
Link Incident Log—Provides the most recent link incidents with their date and time, port number,
and a description of the incident. A link incident can be one of several conditions detected on a
fiber optic link. For a list of events that may cause a link incident to be written to the log, See
This log includes link incidents from all group configuration elements. Individual link incidents
can also be viewed by drilling down to the Element Manager for that group configuration
element.
•
Threshold Alerts Log—Provides notifications of threshold alerts. Besides the date and time that
the alert occurred, it also displays information that was configured through the Threshold Alerts
option under the Configure menu. This includes the date and time alert name, the port for which
the alert is configured, the type of alert (transmit throughput, receive throughput, or both),
percent usage of traffic capacity, minutes the threshold was configured for, and the configured
time interval for the threshold. See ”
•
Open Trunking Log—Provides details on flow rerouting through switch ports. This log displays
only if the optional Open Trunking feature is installed. See ”
•
Security Log—Provides information about security events. See ”
•
Switch Fabric Log (Advanced log)—Provides information about switches in a fabric. See ”
•
Embedded Port Log (Advanced log)—Provides a detailed history log of all traffic passing through
the embedded port. See ”
