Edge Switch Element Manager user guide

15

1

Element Manager overview

This chapter is an introduction to the Element Manager, which is used to manage the HP

StorageWorks Edge Switch 2/24 and Edge Switch 2/32. It is intended as a quick reference for

features available through the main Element Manager window of the High Availability Fabric

Manager (HAFM) application.

Managing the edge switch

, page 15

Element manager description

, page 16

Using the Element Manager

, page 23

Feature keys

, page 19

Backing up and restoring Element Manager data

, page 42

Managing the edge switch

You can manage an edge switch through several different interfaces as follows:

Element Manager and HAFM—Installed on HAFM appliance shipped from the factory. (You can

access the Element Manager through the HAFM application.)

HAFM Basic interface—Using a browser-capable PC with an Internet connection to the switch,

you can monitor and manage the switch through the HAFM Basic interface embedded in the

switch firmware. The interface provides a GUI similar to the Element Manager and supports

switch configuration, statistics monitoring, and basic operation.
To launch the HAFM Basic interface:

1.

Enter the director’s IP address as the Internet Uniform Resource Locator (URL) into any

standard browser.

2.

Enter a user name and password at the login screen. The browser then becomes a

management console. (Refer to the HAFM Basic interface online help or the McDATA EFCM

Basic User Manual for details on use.)

NOTE:

The default user name for the right to view status and other information is

operator

. The default user name for the right to modify configuration data, perform

maintenance tasks, or perform other options is

Administrator

. The default password for

both user names is

password

.

Command Line Interface (CLI)—The CLI allows you to access many HAFM application and

Element Manager functions while entering commands during a Telnet session with the switch.

The primary purpose of the CLI is to automate management of many switches using scripts. The

CLI is not an interactive interface; no checking is done for pre-existing conditions, and no

prompts display to guide users through tasks. Refer to the McDATA E/OS Command Line

Interface User Manual for more information.
