Chapter 1 Specifications Check
28
1.4 Specifications for each Fieldbus
1.4.1 Specifications of DeviceNet Interface
Item Specification
DeviceNet2.0
Group 2 Dedicated Server Communication Protocol
Network-Powered Insulation Node
Baud Rate Automatically follows the master
Communication System Master-Slave System (Polling)
Number of Occupied
Channels
Refer to 3.4.1 PLC Address Construction by each Operation Mode
Number of Occupied
Nodes
1 Node
Baud Rate Max. Network Length
Total Branch
Line Length
Max. Branch Line
Length
500kbps 100m 39m
250kbps 250m 78m
Communication Cable
Length (Note2)
125kbps 500m 156m
6m
Communications Cable Use the dedicated cable.
Connector (Note1) MSTBA2.5/5-G-5.08-ABGY AU (Manufactured by PHOENIX CONTACT or
equivalent)
Consumption Current of
Communication Power
Supply
60mA
Communication Power
Supply
24V DC (Supplied from DeviceNet)
Note1: The cable-side connector is a standard accessory. (SMSTB2.5/5-ST-5.08 AU by PHOENIX CONTACT)
Note2: For T branch communication, refer to the Instruction Manuals for the master unit and programmable logic
controller (stated as PLC from now on) to be mounted.
1.4.2 Specifications of CC-Link Interface
Item Specification
Communication
Protocol
CC-Link Ver1.1 or Ver2
Station Type Remote device station (4 stations max. to occupy)
Baud Rate 10M/5M/2.5M/625K/156kbps
Communication
System
Broadcast Polling System
Number of
Occupied Stations
Refer to 3.4.1 PLC Address Construction by each Operation Mode
Baud Rate [bps] 10M 5M 2.5M 625k 156k Communication
Cable Length (Note2)
Total Cable
Length [m]
100 160 400 900 1200
Communications
Cable
Use the dedicated cable.
Connector (Note1) MSTBA2.5/5-G-5.08 AU (Manufactured by PHOENIX CONTACT or equivalent)
Note1: The cable-side connector is a standard accessory. (SMSTBA2.5/5-ST-5.08 AU by PHOENIX CONTACT)
Note2: For T branch communication, refer to the Instruction Manuals for the master unit and PLC to be mounted.
