Chapter 4 V

ibration Suppress Control Function

236

4.2 Settings of Parameters for Vibration Suppress Control

Set the parameters associated with vibration suppress control, which are listed in the table

below.

Parameter

No.

Parameter

Set No.

Parameter Name

Unit

Default

Input Range

97

Damping characteristic

coefficient 1

Rate

10

0 to 1000

98

Damping characteristic

coefficient 2

Rate

1000

0 to 1000

99

Natural frequency

1/1000Hz

10000

500 to 30000

100

1

Notch filter gain

Rate

9990

1 to 20000

101

Damping characteristic

coefficient 1

Rate

10

0 to 1000

102

Damping characteristic

coefficient 2

Rate

1000

0 to 1000

103

Natural frequency

1/1000Hz

10000

500 to 30000

104

2

Notch filter gain

Rate

9990

1 to 20000

105

Damping characteristic

coefficient 1

Rate

10

0 to 1000

106

Damping characteristic

coefficient 2

Rate

1000

0 to 1000

107

Natural frequency

1/1000Hz

10000

500 to 30000

108

3

Notch filter gain

Rate

9990

1 to 20000

109

Default vibration suppress No.

0

0 to 3

110

Stop method at servo OFF

0

0, 1

[1] Damping characteristic coefficient 1,2 (Parameter No.97, 98, 101, 102, 105, and 106)

Do not change.

[2] Natural frequency [1/1000Hz] (Parameter No.99, 103 and 107)

Set the natural frequency of the load measured. It can be input directly to the parameter

from the frequency analysis tool for anti-vibration control included in the PC software if the

tool is already used. [Refer to the Instruction Manual of the RC PC software.]

Set the specific frequency of the loaded object close to the setting so a higher anti-vibration

performance can be obtained.

[Reference] Other vibration measuring methods

x

Use of measuring instrument such as vibration meter and acceleration

pickup

x

Calculation from video image data

[3] Notch filter gain (Parameter No.100, 104 and 108)

Set the notch filter gain following the table below in response to the measured specific

frequency of the loaded object. See the table below for reference. Provide fine adjustment if

overshooting occurs.

If the notch filter gain setting is too high, overshooting would occur during the settling time.

If the notch filter gain setting is too low, undershooting would occur during the settling time.

Measured Natural

Frequency [Hz]

Setting Value of Notch Filter Gain

0.5

9900

1

9980

2 to 30

9990
