Name for Each Parts and Their Functions
No.0 No.1 No.2 No.3 No.4
No.5
16) Absolute Battery Unit
1) Control power
supply
input connector
3) Regenerative
resistor unit
connector
4) Motor power supply
input connector
6) Fan unit
2) Power supply
status LED
5) Screw terminal
for protective
grounding
7) Driver for Axis No.0 and No.1
10) Operation mode
setting switch
13) Gateway
status LED
11) SIO connector
12) System I/O
connector
15) Fieldbus
connector
14) Field network
status LED
8) Driver for Axis No.2 and No.3
9) Driver for Axis No.4 and No.5
