Actuator
Series
Type
Motor
Output
No. of
Encoder
Pluses
Lead
Oriented
Direction Maximum Speed
Maximum
Acceleration/
Deceleration
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
[W] [mm] [mm/s] [G] [N] [N] [mm/s]
Horizontal 1
ISDBCR
ISPDBCR
(Slider Type)
L (Note) 200 16384 40
Vertical
1800
(at 100 to 800st)
1700
(at to 850st)
1540
(at to 900st)
1410
(at to 950st)
1290
(at to 1000st)
1185
(at to 1050st)
1095
(at to 1100st)
1015
(at to 1150st)
940
(at to 1200st)
875
(at to 1250st)
815
(at to 1300st)
1
㧙 㧙 㧙
(Note) The model stated in the hatched area is applicable for the offboard tuning function (except for the
setting for the high acceleration/deceleration type if any).
For the off board tuning function, refer to the instruction manual for RC PC Software.
