3.4 Fieldbus
Type
Address Map
94
(2) Input and Output Signal Assignment for each Axis
The I/O signals for each axis consists of 4 words for each I/O bit register.
Ɣ The control signals and status signals are ON/OFF signals in units of bit.
Ɣ For the target position and current position, 2-word (32-bit) binary data is available and
values from -999999 to +999999 (unit: 0.01mm) can be used. Negative numbers are to be
dealt with two’s complement.䎃
Ɣ For the indicated position number and complete position number, 1-word (16-bit) binary data
is available and values from 0 to 255 can be used.
PLC Output (m is PLC output top word address for each axis number)
Address m
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
Target
Position
(Lower word)
Address m+1
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
Target
Position
(Upper word)
(Note)If the target position is a negative value, it is indicated by a two’s complement.
䎃
䎃
Address m+2
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
Specified
Position No.
– – – – – – – –
PC128
PC64 PC32 PC16 P
C
8
P
C
4
P
C
2
P
C
1
䎃
䎃
Address m+3
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
Control Signal
B
K
R
L
– – – – – –
JO
G
+
JO
G
-
JV
E
L
JI
S
L
SON R
E
S
S
TP
HOME CSTR
䎃
Caution: Set the position data in the range of the soft stroke (0 to effective stroke length) of
the actuator.
Caution: Set the operational condition in advance with using a teaching tool such as PC
software in the position number to be used. Selecting a position number with no
setting conducted will generate the alarm code 0A2 “Position Data Error”.
1 word=16 bit
