Actuator
Series
Type
Motor
Output
No. of
Encoder
Pluses
Lead
Oriented
Direction Maximum Speed
Maximum
Acceleration/
Deceleration
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
[W] [mm] [mm/s] [G] [N] [N] [mm/s]
Horizontal 0.5
5
Vertical
300
(at 100 to 600st)
270
(at to 650st)
240
(at to 700st)
215
(at to 750st)
190
(at to 800st)
170
(at to 850st)
155
(at to 900st)
140
(at to 950st)
130
(at to 1000st)
120
(at to 1050st)
110
(at to 1100st)
0.4
㧙 㧙 㧙
Horizontal 0.7
ISDBCR
ISPDBCR
(Slider Type)
M (Note)
100
200
16384
10
Vertical
600
(at 100 to 600st)
545
(at to 650st)
480
(at to 700st)
430
(at to 750st)
380
(at to 800st)
345
(at to 850st)
310
(at to 900st)
285
(at to 950st)
260
(at to 1000st)
240
(at to 1050st)
220
(at to 1100st)
0.6
㧙 㧙 㧙
(Note) The model stated in the hatched area is applicable for the offboard tuning function (except for the
setting for the high acceleration/deceleration type if any).
For the off board tuning function, refer to the instruction manual for RC PC Software.
