2.7 Context-sensitive menus
IC Net 2.3 15
*.rtt Report file (ASCII file)
Contains a report template.
The
*.rtt file is stored in the program folder.
*.smt System file (ASCII file)
Contains the system settings.
The
*.smt file is stored automatically in the Systems
folder.
*.dev Device file (ASCII file)
Contains drivers for devices.
The
*.dev file is stored in the Devices folder.
2.7 Context-sensitive menus
Some of the menu functions of the program windows are also ac-
cessible by clicking on the desired window or item and pressing
the right mouse button. The pop up windows have different
contents and functions depending on the selected active window
or item type.
2.8 Keyboard and mouse functions
The mouse can be used to carry out the normal program operat-
ing functions such as the selection of menu items and fields. It
can additionally be used for magnifying a section of a chroma-
togram (zooming). To zoom a portion of the plot it is necessary
to place the mouse cursor to the upper left corner of the square
to zoom, press the left mouse button and drag the cursor to the
lower right corner of the rectangle. After releasing of the left
mouse button the selected region will be zoomed full-screen. If
the cursor is active in the peak editor mode then it can be moved
by pressing down the right-hand mouse key.
The keyboard can also be used to scale a chromatogram in the
window, as described below.
Keyboard quick reference
Cursor is inactive:
[ up ]
Increases sensitivity on the Y axis.
[ down ] Reduces sensitivity on the Y axis.
[ right ] Expands a chromatogram on the X axis.
[ left ] Shrinks a chromatogram on the X axis.
[ Ctrl ] + [ Home ] Autoscale procedure on the X axis (shows
all on X).
[ Ctrl ] + [ End ] Autoscale procedure on the Y axis (shows
all on Y).
[ PageUp ] Shifts a chromatogram on 1 /
10
part of a
screen upwards.
