6.27 861 Advanced Compact IC
IC Net 2.3 239
The 861 icon is available in the system window if a 861 Advanced
Compact IC has been installed with the New system wizard or by us-
ing the Setup/New devices/Install new device option of the SYSTEM
window (see section 6.1.3). If the system is connected, the 861
icon contains two buttons for manual control of the injection
valve at the 861 Advanced Compact IC:
Switch the injection valve to the "Inject" position.
Switch the injection valve to the "Fill" position.
If the system is connected and the 861 icon is clicked with the
right mouse button, the following menu appears:
Open Open the 861 Advanced Compact IC window for
parameter settings (this window can also be
opened by double-clicking the icon).
Hardware
Open the hardware settings window.
Diagnostics Open the diagnostics window (for service per-
sonal only).
Unlink Delete the 861 icon from the system.
6.27.3 861 Advanced Compact IC window
861 icon / Open
The 861 Advanced Compact IC window for parameter settings is
opened by selecting this menu option with the right mouse button
or by clicking the
861 icon on the toolbar. It consists of the four
tabs Control , Program , Configuration , and Links .
Control
The Control tab of the 861 Advanced Compact IC window is only
available for a connected system. It allows manual control of
the 861 Advanced Compact IC functions and setting of startup
values to be sent to the instrument.
