6.25 Metrohm Spark Triathlon Autosampler
IC Net 2.3 199
Tray cooling
The tray cooling is normally not included with the Metrohm Spark
Triathlon Autosampler, but it is available as an option.
Current
Tray temperature, °C Display of the actual tray temperature.
Tray cooling Display of the cooling state.
Only available if the tray cooling is in-
stalled.
Method values
Tray temperature, °C Combo box to select the tray tempera-
ture.
Entry range:
4…40 .
Tray cooling Switch the tray cooling On or Off .
Set the specified values.
For detailed information about the Triathlon Autosampler see
Spark Triathlon user manual.
Actual states
The
Actual states
subtab of the
Manual
tab displays the actual
states of the Triathlon Autosampler, it contains the following
items:
Vial Displays the vial position for the running de-
termination.
Injector valve Displays position of injector valve.
Tray temperature, °C Displays temperature of sample tray, only
available if tray cooling is installed.
AUX 4,3,2,1 Displays the contact closures setting of
connector P5 AUXILLIARIES for remote
control of
AUX 1 – 4 .
OUT 2,1
Displays the contact closures setting of the
two programmable outputs
OUT1 and OUT2
at connector P1 OUTPUTS.
Code output Displays the HEX output at connector P3
TIMED OUTPUTS.
INPUT 4,3,2,1 Displays the values for the four program-
mable inputs at connector P6 INPUTS.
Value:
0
Active low
1 Active high.
