Cross Cutter
Features of the "Cross Cutter" prepared solution
Prepared Solution Servo PLC / ECSxA 1.1 EN 2-75
Outputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
g_dnXAxisTrimmingTPPosOut DINT Displays the actual X trimming position in 0.0001[m_units]. This output indicates the
mark sensor distance set by X trimming. Whenever X trimming is active, this value
will serve as the mark sensor distance for mark correction.
This value is displayed in code C3671/000.
g_nXAxisVelTrimmingFactor_v INT This variable contains the speed value generated for X trimming. It is added to the
DFIN signal in order to effect an immediate change in the position value when using
X trimming.
Inputs/Outputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
g_dnXAxisTrimmingTPPosOut_p DINT This input/output indicates the mark sensor distance set by X trimming. Whenever X
trimming is active, this value will serve as the mark sensor distance for mark
correction. The variable is a retain variable (this means that once an X trimming
value has been calculated, it will remain accessible even after mains switching).
Possible settings: Code
Default Selection
Comment
C3671/
000
- - - - Display code: X trimming outputvalue scaled in 1.0000 m_units
C3672/
002
20.0000 0.0100... {0.01 s} ... 130.0000
Acceleration ramp time for position trimming
C3672/
003
20.0000 0.0100... {0.01 s} ... 130.0000
Deceleration ramp time for position trimming
C3673/
001
200.0000 0 ... {1 rpm} ...15000
Speed for position trimming in a positive direction
C3673/
002
200.0000 0 ... {1 rpm} ...15000
Speed for position trimming in a negative direction
C3674/
000
0.0000 -214748.0000... {0.0001
m_units}
... 214748.0000
Selection of the absolute target trimming position
C3676/
000
10.000 0.000... {0.001 s} ... 999.999
Acceleration ramp time for inching trimming
C3677/
000
10.000 0.000... {0.001 s} ... 999.999
Deceleration ramp time for inching trimming
C3678/
000
0 0 ... {1 rpm} ...15000
Selection of the inching speed
Application control word 18: Activates X trimming and switches
from the calculated mark sensor distance to the mark sensor
distance specified by X trimming.
TRUE X trimming activated.
C4135/
000
Bit 18
0 0 {1} 1
FALSE X trimming deactivated.
Application control word bit 19: Key this bit to perform X trimming
in a positive direction at the set speed.
TRUE Perform X trimming in a positive direction.
C4135/
000
Bit 19
0 0 {1} 1
FALSE Do not perform X trimming.
Application control word bit 20: Key this bit to perform X trimming
in a negative direction at the set speed.
TRUE Perform X trimming in a negative direction.
C4135/
000
Bit 20
0 0 {1} 1
FALSE Do not perform X trimming.
Application status word bit 30: X position trimming is complete
and the target position has been reached.
TRUE The target position has been reached. Positioning is
complete.
C4150/
000
Bit 30
- - - -
FALSE The target position has not been reached.
Positioning is not complete.
