Lenze EVS93xx CrossCutter - Manual (Page 218)

Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-50
Possible settings: Code
Default Selection
Comment
Application control word bit 0: Start/stop homing, only in
conjunction with controller enable.
FALSE => TRUE Start homing.
C4135/
000
Bit 0
0 0 {1} 1
FALSE Stop/abort homing.
Application control word bit 1: Set home position.
FALSE => TRUE The setpoint defined in C3626 (position of
homing switch) is applied and
g_bHomingDone is set to TRUE.
C4135/
000
Bit 1
0 0 {1} 1
FALSE Home position not set.
Application control word bit 2: Reset home position.
TRUE
The home position is reset. The g_bHomingDone
output is reset to FALSE. The "Home position
detected" status is reset.
C4135/
000
Bit 2
0 0 {1} 1
FALSE Home position not reset.
Application control word bit 3: Manual jog in positive direction
(CW)
TRUE Manual jog in positive direction
C4135/
000
Bit 3
0 0 {1} 1
FALSE Stop.
Application control word bit 4: Manual jog in negative direction
(CCW)
TRUE Manual jog in negative direction
C4135/
000
Bit 4
0 0 {1} 1
FALSE Stop.
Application control word bit 5: Execute positioning.
TRUE The drive is moved to the target position along the
set ramps and at the set speed.
C4135/
000
Bit 5
0 0 {1} 1
FALSE Positioning interrupted.
Application control word bit 6: Activation of the external user error.
TRUE External user error pending
C4135/
000
Bit 6
0 0 {1} 1
FALSE No external user error pending
Application control word bit 7: Reset error.
TRUE Resetting error as long as its cause has been
removed.
C4135/
000
Bit 7
0 0 {1} 1
FALSE Not resetting error.
Application control word bit 8: Inhibit controller.
TRUE Controller inhibited (Controller Inhibit).
C4135/
000
Bit 8
0 0 {1} 1
FALSE Controller enabled.
Application control word bit 9: QSP
TRUE Quickstop activ
C4135/
000
Bit 9
0 0 {1} 1
FALSE Quickstop not activ
Application control word bit 10: Activates the DFIN test signal to
simulate the DFIN signal.
TRUE Using the DFIN test signal (g_nTestsignalDFIN_v).
C4135/
000
Bit 10
0 0 {1} 1
FALSE Using the DFIN signal.
Application control word bit 11: Reset cutting counter for cutting
operation.
TRUE
Reset counter.
C4135/
000
Bit 11
0 0 {1} 1
FALSE Counter will not be reset.
Application control word bit 12: Reset cutting counter for reject
operation.
TRUE Reset counter.
C4135/
000
Bit 12
0 0 {1} 1
FALSE Counter will not be reset.
