Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-7
Outputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
Status signal: Calculation sequence for new cross-cutter motion profile for a new
cutting length completed successfully.
TRUE
Calculation sequence for new cross-
cutter motion profile for a new cutting
length completed successfully.
Starting a new calculation sequence will
reset this status output to FALSE.
g_bCrossCutterCalcDoneCuttingProfile BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new cutting
length not completed.
Status signal: Calculation sequence for new cross-cutter motion profile for a new
reject length completed successfully.
TRUE
Calculation sequence for new cross-
cutter motion profile for a new reject
length completed successfully.
Starting a new calculation sequence will
reset this status output to FALSE.
g_bCrossCutterCalcDoneRejectProfile BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new reject
length not completed.
Status signal: Calculation sequence for new cross-cutter motion profile for a new
test length completed successfully.
TRUE
Calculation sequence for new cross-
cutter motion profile for a new test length
completed successfully.
Starting a new calculation sequence will
reset this status output to FALSE.
g_bCrossCutterCalcDoneTestProfile BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new test length
not completed.
Status signal: Calculation sequence for new cross-cutter motion profile for a new
start/stop length completed successfully.
TRUE
Calculation sequence for new cross-
cutter motion profile for a new start/stop
length completed successfully.
Starting a new calculation sequence will
reset this status output to FALSE.
g_bCrossCutterCalcDoneStartStopProfile BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new start/stop
length not completed.
Status signal: Calculation sequence for new cross-cutter motion profile for a new
asynchronus length completed successfully.
TRUE
Calculation sequence for new cross-
cutter motion profile for a new
asynchronus length completed
successfully.
Starting a new calculation sequence will
reset this status output to FALSE.
g_bCrossCutterCalcDoneAsyCuttingProfile BOOL
FALSE Calculation sequence for new cross-
cutter motion profile for a new
asynchronus length not completed.
