Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-1
6 Appendix
6.1 Global variables
6.1.1 VarCrossCutterBasics
Inputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
Activate the DFIN simulation signal g_nTestsignalDFIN_v for test purposes.
TRUE
Test signal in use. Signals from DFIN
will be ignored.
g_bUseTestsignal BOOL
FALSE
Test signal not in use. Signals from
DFIN used for master value generation.
g_nTestsignalDFIN_v INT Speed signal for the simulation of the DFIN signal for test purposes. This value is
only used if the g_bUseTestsignal global variable = TRUE.
Switch-over between metric and imperial measuring systems
TRUE
DDS visualisation is working in [inch].
g_bImperialUnits BOOL
FALSE DDS visualisation is working in [mm].
Invert DFIN signal.
TRUE
Inverting incoming signals from the DFIN
signal.
g_bInvertDFINSignal BOOL
FALSE
Not inverting incoming signals from the
DFIN signal.
g_dnCamPositionSet DINT Current position of motion profile of cross-cutter drum in 0.0001[s_units].
g_dnToolPositionAct DINT Current position of cross-cutter drum in 0.0001[s_units].
g_dnVertShaftPosAct DINT Current position of master value in 0.0001[m_units].
g_dnFollowError DINT Current following error in 0.0001[s_units].
