Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-18
Outputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
Status signal: The cross cutter is operating in "Test operation" mode.
TRUE
The cross cutter is operating in "Test
operation" mode.
g_bUseTestProfile BOOL
FALSE The cross cutter is not operating in "Test
operation" mode.
Activate and deactivate speed value for master value.
TRUE
Send speed value.
g_bStartDFIN BOOL
FALSE Set speed to zero.
Reset g_bStopDFIN variable.
TRUE
g_bStopDFIN reset.
g_bResetStopDFIN BOOL
FALSE g_bStopDFIN not reset.
6.1.6 VarCrossCutterRejectGate
Inputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
g_wRejectGateSwitchingDwelltime WORD Selection of the switching dwell time (switching delay time) of the reject gate in ms.
g_dnDistanceRejectGate DINT Selection of the distance from the reject gate to the cutting position in
0.0001[m_units].
The value is converted into increments internally. If you use this variable, to avoid
inconsistencies, do not write variable g_dnDistanceRejectGate_p!
g_dnDistanceRejectGate_p DINT Selection of the distance from the reject gate to the cutting position in [incr.].
If you use this variable, to avoid inconsistencies, do not write variable
g_dnDistanceRejectGate!
Outputs
Global variables (Variable type: VAR_GLOBAL)
Name Data type Value/Meaning
This output is used to control the reject gate.
TRUE Open the reject gate.
g_bOpenRejectGate BOOL
FALSE Do not open the reject gate.
