Lenze EVS93xx CrossCutter - Manual (Page 225)

Cross Cutter
Appendix
Prepared Solution Servo PLC / ECSxA 1.1 EN 6-57
6.2.2 Code initialisation values
The following codes are initialised on a project-specific basis and differ from the default setting
initialisation values.
Code Initialisation Comment
C0114/001 1,0000 Inversion of digital input I1 (0V = QSP) using 9300 Servo PLC
C0114/004 1,0000 Inversion of digital input I4 (0V = QSP) using ECS
C0352/000 1,0000 Device declared as CAN boot-up master.
C0427/000 0,0000 DFIN function of master signal is "2 phases".
C0428/000 1,0000 DFIN touch-probe source is digital input I5 (terminal X5/I5).
C0469/000 0,0000 Deactivation of stop pushbutton (keypad)
C0540/000 4,0000 DFOUT X9=X10
C2104/000 1,0000 PLC auto-start
C3649/001 0.1000 Time for abort ramp during print-mark synchronisation
C4010/002 1,0000 Control bit 1 Home position set read from input bit 1
C4010/003 2,0000 Control bit 2 Home position reset read from input bit 2
C4010/004 3,0000 Control bit 3 Manual jog in positiv read from input bit 3
C4010/005 4,0000 Control bit 4 Manual jog in negativ read from input bit 4
C4010/006 5,0000 Control bit 5 Positioning start read from input bit 5
C4010/007 6,0000 Control bit 6 User trip set read from input bit 6
C4010/008 7,0000 Control bit 7 Trip reset read from input bit 7
C4010/009 8,0000 Control bit 8 Controller inhibit read from input bit 8
C4010/010 9,0000 Control bit 9 Quickstop read from input bit 9
C4010/011 10,0000 Control bit 10 Switch to internal line speed (C3681) read from input bit 10
C4010/012 11,0000 Control bit 11 Reset cutting length counter read from input bit 11
C4010/013 12,0000 Control bit 12 Reset reject length counter read from input bit 12
C4010/014 13,0000 Control bit 13 Reset test length counter read from input bit 13
C4010/015 14,0000 Control bit 14 Automatic mode (Cross cutter operation) read from input bit 14
C4010/016 15,0000 Control bit 15 Accept cutting length read from input bit 15
C4010/017 16,0000 Control bit 16 Accept reject length read from input bit 16
C4010/018 17,0000 Control bit 17 Accept test length read from input bit 17
C4010/019 18,0000 Control bit 18 Activate x-trimming read from input bit 18
C4010/020 19,0000 Control bit 19 Positiv x-trimming read from input bit 19
C4010/021 20,0000 Control bit 20 Negativ x-trimming read from input bit 20
C4010/022 21,0000 Control bit 21 Enable print-mark controller read from input bit 21
C4010/023 22,0000 Control bit 22 Ramp based adjustment read from input bit 22
C4010/024 23,0000 Control bit 23 Reset missingmark counter read from input bit 23
C4010/025 24,0000 Control bit 24 Abort cross cutter operation read from input bit 24
C4010/026 25,0000 Control bit 25 Activate x-trimming positioning read from input bit 25
C4010/027 26,0000 Control bit 26 not assigned read from input bit 26
C4010/028 27,0000 Control bit 27 not assigned read from input bit 27
C4010/029 28,0000 Control bit 28 not assigned read from input bit 28
C4010/030 29,0000 Control bit 29 not assigned read from input bit 29
C4010/031 30,0000 Control bit 30 not assigned read from input bit 30
C4010/032 31,0000 Control bit 31 not assigned read from input bit 31
C4012/002 1,0000 Status bit 1 output to output bit 1, Follow error warning
C4012/003 2,0000 Status bit 2 output to output bit 2, Follow error trip
C4012/004 3,0000 Status bit 3 output to output bit 3, Positioning active
C4012/005 4,0000 Status bit 4 output to output bit 4, Positioning done
C4012/006 5,0000 Status bit 5 output to output bit 5, Lock to cam busy
C4012/007 6,0000 Status bit 6 output to output bit 6, Cross Cutter Operation
C4012/008 7,0000 Status bit 7 output to output bit 7, Print mark correction active
C4012/009 8,0000 Status bit 8 output to output bit 8, Recalculation of cutting profile
C4012/010 9,0000 Status bit 9 output to output bit 9, Recalculation of reject profile
C4012/011 10,0000 Status bit 10 output to output bit 10, Recalculation of test profile
C4012/012 11,0000 Status bit 11 output to output bit 11, Recalculation of start/stop profile
C4012/013 12,0000 Status bit 12 output to output bit 12, Calculation of cutting profile OK
C4012/014 13,0000 Status bit 13 output to output bit 13, Calculation of reject profile OK
C4012/015 14,0000 Status bit 14 output to output bit 14, Calculation of test profile OK
C4012/016 15,0000 Status bit 15 output to output bit 15, Calculation of start/stop profile OK
C4012/017 16,0000 Status bit 16 output to output bit 16, Homing busy
C4012/018 17,0000 Status bit 17 output to output bit 17, Home position available
C4012/019 18,0000 Status bit 18 output to output bit 18, Homing error
C4012/020 19,0000 Status bit 19 output to output bit 19, NC
C4012/021 20,0000 Status bit 20 output to output bit 20, Asynchronus cutting operation
